SC/APC Fiber Optic Pigtail Single Mode 9/125 0.9mm 1.0m LSZH

O/PC/F to MPO/PC/F for OM3 with 12B 3.0mm for 1M/5M/10M OFNP/LSZH Aqua B

MPO Patch Cord

Descriptions:

The single-mode and multimode MPO products are multi fiber connectors used in high-density backplane and Printed Circuit Board(PCB) applications in data and telecommunications system. The MPO connector offers up to 12 times the density of standard connectors, providing significant space and cost savings.
MPO patch cord utilize precision molded MT ferrules, with metal guide pins and precise housing dimensions to ensure fiber alignment when mating. The MPO can be mass terminated in combination of 4,8,12 or 24 fibers.

Features:

• Precision molded MT ferrule
• High precision guide pins for exact alignment
• Compact design, up to 4,8,12,24 fibers
• IEC 61754-7 Compliant
• Telcordia GR-1435-CORE Compliant

Application:

• Asynchronous Transmission Mode(ATM)
• Gigabit Ethernet
• Active Deviced/Transceiver Interface
• CATV, Video and Multimedia
• Premise Installations
• Telecommunication Networks
• Parallel optical interconnect between PC Cards and patch panels
• Interconnection for O/E modules
• Industrial & Military
• Optical Switch interframe connections

Specifications:

OEM/ODM Service:

If you want to display your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.

Packing:

According to Stardard Export Packing.

Carton box, wooden box, wooden pallet.

Shipping:

- International express such as UPS, TNT, DHL, etc

- Internatioal air: CA, AA, EA, etc

- By sea
